PRODUCT DETAILS
430-460 W
High Efficiency Monocrystalline
Solar Module 430-460W
0~+3% Positive tolerance
IEC61215(2016), IEC61730(2016)
IEC61215(2016), IEC61730(2016)
ISO9001:2015: Quality Management System
ISO14001:2015: Environmental Management System
Module Features
1. Half-Cell (HC) Technology
Lower Energy
By using half-cells, the electrical current ( flowing in each busbar is halved.Therefore, the
amount of internal losses in a half-cut module is 1/4 of a full-sized cel module
By using half-cells, the electrical current ( flowing in each busbar is halved.Therefore, the
amount of internal losses in a half-cut module is 1/4 of a full-sized cel module
Lower Shading Loss
Shading loss of half-cell is improved compared to a regular module in
specific shading conditions.
Shading loss of half-cell is improved compared to a regular module in
specific shading conditions.
2.Multi Busbars Technology
Better light utilization and current collection ability, effective improving the power output and reliability.
Better light utilization and current collection ability, effective improving the power output and reliability.
3.Operational in Harsh Environment
High salt spray and high ammonia corrosion test certificated by the third party.
High salt spray and high ammonia corrosion test certificated by the third party.
4.Better Resistance to Hot Spots
Obtaining better temperature coefficient and resistance to hot spots by optimizing the circuit design and operating current.
Obtaining better temperature coefficient and resistance to hot spots by optimizing the circuit design and operating current.
5.Load Capability
2400Pa wind load and 5400Pa snow load certification.
2400Pa wind load and 5400Pa snow load certification.
6.Anti PID Assurance
Minimizing the attenuation probability caused by the PID phenomenon through optimized solar cell production technology and material control.
Minimizing the attenuation probability caused by the PID phenomenon through optimized solar cell production technology and material control.
Industry Leading Linear Warranty
10-year warranty for material & craft
25-year linear warranty
Exceptional warranty commitment 25 years power warranty
0.55% linear power attenuation
25-year linear warranty
Exceptional warranty commitment 25 years power warranty
0.55% linear power attenuation
