51.2V 100AH Wall Mounted Series Battery LiFePo4

Regular price ¥0.00

/
The Rack Server LiFePO4 battery pack 51.2V  LiFePO4 not only has a built-in BMSsystem but has an integrated LCD screen that helps users quickly identify any issues and or quickly adjust any settings. This 51.2V battery pack can be used...

PRODUCT DETAILS

The Rack Server LiFePO4 battery pack 51.2V  LiFePO4 not only has a built-in BMS
system but has an integrated LCD screen that helps users quickly identify any issues and or quickly adjust any settings.

This 51.2V battery pack can be used in parallel systems; it has significant advantages as a backup battery
for communication equipment.
The 51.2V LiFePO4 features high power density, small size, long service life, resistance to high temperature,
fast charging and discharging, and an effective modular design.

CHARACTERISTICS

1. Positive electrodes made of LiFePO4 (LFP), ensuring higher safety and a long service life.
2. Compatible with a variety of power supply devices.
3. Built-in BMS system with multiple protections and communication functions, which ensures high reliability of the battery pack and enables real-time monitoring of battery data over a long distance.
4. Low internal resistance, with efficient internal balance of the battery control circuit.
5. Wide working temperature range and high reliability.
6. Support for parallel connection of battery packs, max16p

FEATURES

• RS485/232/Can communication output for monitoring.
• Built-in BMS with charging current limitation.
• Built-in automatic protection for over-charge, over-discharge, low-temperature, and Over-temperature protections.
• State of charge and state of health indication.
• Built-in battery control for efficient operation.
• Internal cell balancing.
• Maintenance free system.

Communication Protocal: LCF/Heating/CAN/485/232

Storage Time Charging
The Normal Voltage is Charged once every 3 months, and the voltage of 10-10.5V must be charged the next day.

Battery Protection
Overcharge Protection, Overydischarge Protection, Overcurrent Protection, Short-Circuit
Protection, Overtemperature Protection

Inverter Connection Brand
GOODWE, PYLONTECH, SOLARAM, Victron Energy, GROWATT, SolaXPower, SOFAR, LUXPower, MUST, LTW, SOROREC, MEGAREVO, Voltronic Power, SRNE, PYLONTECH, DEYE, etc.

APPLICATION
Telecom Power-Post and Telecommunications, Communications, Power Stations, Power
Transmission, UPS, Computer Systems, Ligjting Systems, Solar Energy, Wind Energy, Home Energy Storage, etc.

GENERAL
INFORMATION

Casing MaterialSteel case
Assembly16S1P Single cell Capacity 100Ah
Cell (LiFePo4)Lithium-ion Cell:EVE/BYD/CATL
Recommended Charging TypeCC-CV-Float charge
BMSIntegrated with LCD display

SPECIFICATIONS

Voltage51.2 V
Nominal Capacity
(0.2°C, 5A)
100 Ah
Normal Energy
(0.2°C , 5A)
5120WH
Max. Charge Current50 A
Max. Constant Discharge Current100 A
Charge Voltage57 V
Cut-off Voltage45 V
Cycle Life (0.2C, 25°C)3000 with 100% DOD
4000 with 80% DOD
8000 with 50% DOD
Warranty Period5 years
Charging StandardCC: 0.2C to 57V
CV: 57V
Floating: 55.2V – 57V
Charging end current: 0.01C
Operating TemperatureCharging: 23 – 131°F / -5  – 55°C
Discharging: -22 - 131°F / -30  – 55°C
Storage Time / Temperature -5 - 95°F/ -20  – 35°C



MECHANICAL SPECIFICATIONS

Dimensions (L x W x H)580*450*210mm
Weight58kg
TerminalM6
Mounting OptionsFloor or Rack mount
